Product Summary
The bipolar transistor BC807-40, also called junction type transistor, ia a kind of transistor. Unlike field-effect transistor (unipolar transistors), it is also called bipolar because it has two kinds of carriers (hole, electron).
Parametrics
BC807-40 absolute maximum ratings:(1)collector-emitter voltage(VCEO) is 45 Vdc(open base and Ic is 10 mA); (2) collector-base voltage(VCBO)is -50 Vdc(open emitter); (3)emitter-base voltage(VEBO) is -5.0 Vdc(open collector); (4) collector current-DC(Ic) is -500 mAdc; (5)total power dissipation(Ptot) is 250 mW when Tamb is not higher than 25℃; (6)junction temperature(Tj) is 150℃; (7)storage temperature(Tstg) is -65℃ to 150℃.
Features
BC807-40 features: (1) high current which is max 500 mA; (2) low voltage which is max 45V.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BC807-40 /T3 |
NXP Semiconductors |
Transistors Bipolar (BJT) TRANS GP TAPE-13 |
Data Sheet |
Negotiable |
|
||||||||||||
|
BC807-40,215 |
NXP Semiconductors |
Transistors Bipolar (BJT) PNP GP 500MA 45V |
Data Sheet |
|
|
||||||||||||
|
BC807-40,235 |
NXP Semiconductors |
Transistors Bipolar (BJT) TRANS GP TAPE-13 |
Data Sheet |
|
|
||||||||||||
 |
BC807-40-7 |
Diodes Inc. |
Transistors Bipolar (BJT) PNP BIPOLAR |
Data Sheet |
Negotiable |
|
||||||||||||
|
BC807-40-7-F |
Diodes Inc. |
Transistors Bipolar (BJT) PNP BIPOLAR |
Data Sheet |
|
|
||||||||||||
 |
BC807-40LT1 |
ON Semiconductor |
Transistors Bipolar (BJT) 500mA 50V PNP |
Data Sheet |
Negotiable |
|
||||||||||||
|
BC807-40LT1G |
ON Semiconductor |
Transistors Bipolar (BJT) 500mA 50V PNP |
Data Sheet |
|
|
||||||||||||
|
BC807-40LT3 |
ON Semiconductor |
Transistors Bipolar (BJT) 500mA 50V PNP |
Data Sheet |
Negotiable |
|
||||||||||||
