Product Summary
The ltv817 is a High Density Mounting Type Photocoupler. The applications of the ltv817 include Computer terminals, System appliances, measuring instruments, Registers, copiers, automatic vending machines, Electric home appliances such as fan heaters, etc.
Parametrics
ltv817 absolute maximum ratings: (1)Forward Current: 50 mA; (2)Reverse Voltage: 6 V; (3)Power Dissipation: 70 mW; (4)Collector-Emitter Voltage: 35 V; (5)Emitter-Collector Voltage: 6 V; (6)Collector Current: 50 mA; (7)Collector Power Dissipation: 150 mW; (8)Total Power Dissipation: 200 mW; (9)Operating Temperature: -30 to +100 ℃; (10)Storage Temperature: -55 to +125 ℃.
Features
ltv817 features: (1)Current transfer ratio (CTR : MIN. 50% at IF=5mA, VCE=5V); (2)High input-output isolation voltage: (VISO : 5,000Vrms); (3)Compact dual-in-line package: LTV-817 : 1-channel type, LTV-827 : 2-channel type, LTV-847 : 4-channel type; (4)UL approved (No. E113898); (5)TUV approved (No. R9653630); (6)CSA approved (No. CA91533-1); (7)FIMKO approved (No. 202634); (8)NEMKO approved (No. P98101945).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 LTV817C |
Other |
|
Data Sheet |
Negotiable |
|
||||
