Product Summary

The BC847 is a NPN general-purpose transistor. The applications of it are General-purpose switching and amplification.

Parametrics

BC847 absolute maximum ratings: (1)collector-base voltage:50 V; (2)collector-emitter voltage:45 V; (3)emitter-base voltage:6 V; (4)collector current:100 mA; (5)peak collector current:200 mA; (6)peak base current:100 mA; (7)total power dissipation:250 mW; (8)junction temperature:150℃; (9)ambient temperature:-65℃ to +150℃; (10)storage temperature:-65℃ to +150℃.

Features

BC847 features: (1)Low current; (2)Low voltage; (3)Three different gain selections.

Diagrams

BC847 pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
BC847
BC847
Rectron
Transistors Bipolar (BJT) Gen Pur Trans NPN,0.1A,45V
Data Sheet
0-3000: $0.04
3000-6000: $0.03
6000-12000: $0.03
BC847,235
BC847,235
NXP Semiconductors
Transistors Bipolar (BJT) TRANS GP TAPE-13
Data Sheet
0-1: $0.03
1-25: $0.03
25-100: $0.03
100-250: $0.02
BC847A /T3
BC847A /T3
NXP Semiconductors
Transistors Bipolar (BJT) TRANS GP TAPE-13
Data Sheet
Negotiable
BC847A,215
BC847A,215
NXP Semiconductors
Transistors Bipolar (BJT) TRANS GP TAPE-7
Data Sheet
0-1: $0.03
1-25: $0.01
25-100: $0.01
100-500: $0.01
500-3000: $0.01
BC847A-7
BC847A-7
Diodes Inc.
Transistors Bipolar (BJT) NPN BIPOLAR
Data Sheet
Negotiable
BC847A-7-F
BC847A-7-F
Diodes Inc.
Transistors Bipolar (BJT) NPN BIPOLAR
Data Sheet
0-1: $0.28
1-10: $0.17
10-100: $0.08
100-250: $0.05
BC847A-GS08
BC847A-GS08
Vishay Semiconductors
Transistors Bipolar (BJT) NPN Switching/AF Amp
Data Sheet
Negotiable
BC847ALT1
BC847ALT1
ON Semiconductor
Transistors Bipolar (BJT) 100mA 50V NPN
Data Sheet
Negotiable
