ISL6236

dual step-down, switch-mode power-supply controller, QFN-32, -0.3V to +27V, Wide Input Voltage Range

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: ISL6236

Brand:: Intersil Corporation - Intersil | Pack: QFN | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Elaine Huang's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-10

From Other Seller

Part Number:ISL6236
US $1.00 - 2.00
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ISL6236 is a dual step-down, switch-mode power-supply (SMPS) controller. It generates logic-supply voltages in battery-powered systems. The ISL6236 include two pulse-width modulation (PWM) controllers, 5V/3.3V and 1.5V/1.05V. The ISL6236 features a linear regulator providing 3.3V/5V, or adjustable from 0.7V to 4.5V output via LDOREFIN. The linear regulator provides up to 100mA output current with automatic linear-regulator bootstrapping to the BYP input. When in switchover, the LDO output can source up to 200mA. The ISL6236 includes on-board power-up sequencing, the power-good (POK) outputs, digital soft-start, and internal soft-stop output discharge that prevents negative voltages on shutdown.

Parametrics

ISL6236 absolute maximum ratings: (1)VIN, EN LDO to GND: -0.3V to +27V; (2)BOOT to GND: -0.3V to +33V; (3)BOOT to PHASE: -0.3V to +6V; (4)VCC, EN, SKIP, TON, PVCC, POK to GND: -0.3V to +6V; (5)LDO, FB1, REFIN2, LDOREFIN to GND: -0.3V to (VCC + 0.3V); (6)OUT, SECFB, VREF3, REF to GND: -0.3V to (VCC + 0.3V; (7)UGATE to PHASE: -0.3V to (PVCC + 0.3V); (8)ILIM to GND: -0.3V to (VCC + 0.3V); (9)LGATE, BYP to GND: -0.3V to (PVCC + 0.3V); (10)PGND to GND: -0.3V to +0.3V; (11)LDO, REF, VREF3 Short Circuit to GND: Continuous; (12)VCC Short Circuit to GND: 1s; (13)LDO Current (Internal Regulator) Continuous: 100mA; (14)LDO Current (Switched Over to OUT1) Continuous: +200mA.
