Product Summary
The OP400GP is a monolithic quad operational amplifier that features OP77 type performance. Precision performance no longer has to be sacrificed to obtain the space and cost savings offered by quad amplifiers. The OP400GP features an extremely low input offset voltage of less than 150 mV with a drift of under 1.2 mV/∞C, guaranteed over the full military temperature range. Open-loop gain of the OP400 is over 5,000,000 into a 10 kW load, input bias current is under 3 nA, CMR is above 120 dB, and PSRR is below 1.8 mV/V.
Parametrics
OP400GP absolute maximum ratings: (1)supply Voltage: ±20 V; (2)Differential Input Voltage: ±30 V; (3)Input Voltage: Supply voltage; (4)Output Short-Circuit Duration: Continuous; (5)Storage Temperature Range: -65 to +150℃; (6)Lead Temperature (Soldering 60 sec): 300℃; (7)Junction Temperature (TJ) Range: -65 to +150℃; (8)Operating Temperature Range: 0 to 70℃.
Features
OP400GP features: (1)Low Input Offset Voltage 150 μV Max; (2)Low Offset Voltage Drift, Over –55 to +125℃, 1.2 pV/℃ Max; (3)Low Supply Current (Per Amplifier) 725 μA Max; (4)High Open-Loop Gain 5000 V/mV Min; (5)Input Bias Current 3 nA Max; (6)Low Noise Voltage Density 11 nV/Hz at 1 kHz; (7)Stable With Large Capacitive Loads 10 nF Typ; (8)Pin Compatible to LM148, HA4741, RM4156, and LT1014 with Improved Performance; (9)Available in Die Form.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 OP400GP |
|
IC OPAMP GP 500KHZ QUAD LP 14DIP |
Data Sheet |
|
|
||||||||||||||||
|
OP400GPZ |
|
IC OPAMP GP 500KHZ QUAD LP 14DIP |
Data Sheet |
|
|
||||||||||||||||
