Product Summary

The TOSHIBA TLP126 mini flat coupler is a small outline coupler, suitable for surface mount assembly. The TLP126 consists of a photo transistor, optically coupled to a gallium arsenide infrared emitting diode connected inverse parallel, and provides high CTR at low AC input current.

Parametrics

TLP126 absolute maximum ratings: (1)Forward current: 50 mA; (2)Forward current derating (Ta≥ 53℃): -0.7 mA/℃; (3)Peak forward current(100μs pulse,100pps): 1 A; (4)Junction temperature: 125 ℃; (5)Collector-emitter voltage: 80 V; (6)Emitter-collector voltage: 7 V; (7)Collector current: 50 mA; (8)Peak collector current(10ms pulse,100pps): 100 mA; (9)Power dissipation: 150 mW; (10)Power dissipation derating (Ta ≥ 25℃): -1.5 mW/℃; (11)Junction temperature: 125 ℃.

Features

TLP126 features: (1)Collector-emitter voltage: 80 V (min.); (2)Current transfer ratio: 100% (min.); (3)Isolation voltage: 3750Vrms (min.); (4)UL recognized: UL1577, file No. E67349.

Diagrams

TLP126 pin configuration diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TLP126(F)
TLP126(F)
Toshiba
Transistor Output Optocouplers 80Vceo 3750Vrms AC input
Data Sheet
0-1: $0.45
1-10: $0.36
10-100: $0.31
100-250: $0.27
TLP126TPRF
TLP126TPRF
Toshiba
Transistor Output Optocouplers 80Vceo 3750Vrms AC input
Data Sheet
0-1: $0.52
1-10: $0.43
10-100: $0.35
100-250: $0.27
TLP126-TPL
TLP126-TPL
Other

Data Sheet
Negotiable
TLP126(TPR,F)
TLP126(TPR,F)

PHOTOCOUPLER TRANS OUT 6MFSOP-4
Data Sheet
0-3000: $0.25
3000-6000: $0.24
6000-15000: $0.23
15000-30000: $0.22
30000-75000: $0.22
TLP126(TPR)
TLP126(TPR)

PHOTOCOUPLER TRANS OUT 6MFSOP-4
Data Sheet
Negotiable
TLP126
TLP126

PHOTOCOUPLER TRANS OUT 6MFSOP-4
Data Sheet
Negotiable
