Product Summary

The LP101WS1-TLB1 is a DC/DC Converter.

Parametrics

LP101WS1-TLB1 absolute maximum ratings: (1)Voltage Accuracy Single Output: ±1% max., Dual Output: ±1% max., Triple 5V: ±2% max., 12V/15V: ±1% max.; (2)Voltage Balance, Dual Output at Full Load: ±1% max.; (3)Transient Response: Single, 25% Step Load Change <500μ sec., Dual, FL-1/2L±1% Error Band <500μ sec.; (4)External Trim Adj. Range: ±5%; (5)Ripple & Noise, 20MHz BW: 10mV RMS, max.; (6)1% P-P max; (7)Temperature Coefficient: ±0.02%/℃ max.; (8)Short Circuit Protection: Indefinite; (9)Overvoltage Protection, 5V: 6.8V.

Features

LP101WS1-TLB1 features: (1)2:1 Input Range; (2)External Output Trim; (3)Isolated Outputs; (4)Remote Disable; (5)Efficiency to 84%; (6)Six-sided Shield; (7)100 kHz Switching Frequency; (8)PCB Mountable.

Diagrams

LP101WS1-TLB1 diagram
