Product Summary

The LP3340 is a 3 mm (T1) LED.

Parametrics

LP3340 absolute maximum ratings: (1)Operating temperature range:-55℃ to +100℃; (2)Storage temperature range:-55℃ to +100℃; (3)Junction temperature:+100; (4)Forward current:30mA; (5)Surge current:0.5A; (6)Reverse voltage:5V; (7)Power dissipation:100mW; (8)Thermal resistance Junction / air:400K/W.

Features

LP3340 features: (1)colored, clear package; (2)optical coupling into light pipes; (3)for use as optical indicator; (4)solder leads with stand-off; (5)available taped on reel; (6)load dump resistant acc. to DIN 40839.

Diagrams

LP3340 package dimensions
