S80C196MC

industrial motor control microcontroller, 80-MQFP, 16MHz, High-Performance, CHMOS 16-Bit CPU

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: S80C196MC

Brand:: Intel Corporation - Intel | Pack: PLCC | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Elaine Huang's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-04

From Other Seller

Part Number:S80C196MC
US $1.00 - 2.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The S80C196MC is a 16-bit microcontroller designed primarily to control 3 phase AC induction and DC brushless motors. The S80C196MC is based on Intel’s MCSE 96 16-bit microcontroller architecture and is manufactured with Intel’s CHMOS process. The S80C196MC has 16 Kbytes on-chip OTPROM/ROM and 488 bytes of on-chip RAM. It is available in three packages; PLCC (84-L), SDIP (64-L) and EIAJ/QFP (80-L). It generates 3 complementary non-overlapping PWM pulses with resolutions of 0.125 μs (edge trigger) or 0.250 μs(centered).

Parametrics

S80C196MC absolute maximum ratings: (1)Ambient Temperature Under Bias:-40℃ to +85℃; (2)Storage Temperature:-65℃to +150℃; (3)Voltage from EA or VPP to VSS or ANGND:+13.00V; (4)Voltage on VPP or EQ to VSS or ANGND:-0.5V to 13.0V; (5)Voltage on Any Other Pin to VSS or ANGND:-0.5V to +7.0V; (6)Power Dissipation:1.5W.

Features

S80C196MC features: (1)High-Performance CHMOS 16-Bit CPU; (2)16 Kbytes of On-Chip OTPROM/Factory-Programmed OTPROM; (3)488 bytes of On-Chip Register RAM; (4)Register to Register Architecture; (5)Up to 53 I/O Lines; (6)Peripheral Transaction Server (PTS) with 11 Prioritized Sources; (7)Event Processor Array (EPA): 4 High Speed Capture/Compare Modules, 4 High Speed Compare Modules; (8)Extended Temperature Standard; (9)Two 16-Bit Timers with Quadrature Decoder Input; (10)3-Phase Complementary Waveform Generator; (11)13 Channel 8/10-Bit A/D with Sample/Hold with Zero Offset Adjustment H/W; (12)14 Prioritized Interrupt Sources; (13)Flexible 8-/16-Bit External Bus; (14)1.75 μs 16 x 16 Multiply; (15)3 μs 32/16 Divide; (16)Idle and Power Down Modes.
