Product Summary
The LM2576T-ADJ is a simple switche 3A step-down voltage regulator. The LM2576T-ADJ regulator is a monolithic integrated circuit that provides all the active functions for a step-down (buck) switching regulator, capable of driving 3A load with excellent line and load regulation. The LM2576T-ADJ is available in fixed output voltages of 3.3V, 5V, 12V, 15V, and an adjustable output version. Requiring a minimum number of external components, the regulator LM2576T-ADJ is simple to use and include internal frequency compensation and a fixed-frequency oscillator.
Parametrics
LM2576T-ADJ absolute maximum ratings: (1)Maximum Supply Voltage: 45V; (2)ON /OFF Pin Input Voltage: -0.3V ≤ V ≤ +VIN; (3)Output Voltage to Ground(Steady State): -1V; (4)Power Dissipation: Internally Limited; (5)Storage Temperature Range: -65℃ to +150℃; (6)Maximum Junction Temperature: 150℃; (7)Minimum ESD Rating(C = 100 pF, R = 1.5 kΩ): 2kV; (8)Lead Temperature(Soldering, 10 Seconds): 260℃.
Features
LM2576T-ADJ features: (1)Guaranteed 3A output current; (2)Wide input voltage range, 40V up to 60V for HV version; (3)Requires only 4 external components; (4)52 kHz fixed frequency internal oscillator; (5)TTL shutdowcapability, low power standby mode; (6)High efficiency; (7)Uses readily available standard inductors; (8)Thermal shutdowand current limit protection; (9)P+ Product Enhancement tested.
Diagrams
